DSR119 Forged Lever Load Binders 模锻杠杆式紧索具
|
ITEM NO. |
Working Load Limit (LBS) |
Proof Load (LBS) |
Ultimate Load (LBS) |
Weight Each (LBS) |
Handle Length (in) |
Take Up (in) |
Dimensions (in.) |
||||||
|
A |
B |
C |
D |
E |
F |
G |
|||||||
|
1/4-5/16 |
2200 |
4400 |
7800 |
3.52 |
11.42 |
3.75 |
18.5 |
17.3 |
14.17 |
11.42 |
8.27 |
8.27 |
0.35 |
|
5/16-3/8 |
5400 |
10800 |
19000 |
7.02 |
16.00 |
4.50 |
24.13 |
22.13 |
17.88 |
16.00 |
10.38 |
10.38 |
0.50 |
|
3/8-1/2 |
9200 |
18400 |
33000 |
12.47 |
18.69 |
4.50 |
28.75 |
25.75 |
21.25 |
18.69 |
12.31 |
12.38 |
0.63 |
|
1/2-5/8 |
13000 |
26000 |
46000 |
13000 |
21.00 |
4.75 |
31.25 |
29.75 |
25.00 |
21.00 |
14.63 |
13.75 |
0.72 |
