ITEM NO. (in.)

Working Load Limit (LBS)

Proof Load (LBS)

Weight Each (LBS)

Handle Length (in)

Barrel Length (in)

Take Up (in)

Dimensions (in)

A

B

C

E

E1

F

F1

G

1/4-5/16

2200

4400

3.52

7.16

6.3

4.65

7.16

0.89

1.77

16.22

21.26

17.79

31.23

0.35

5/16-3/8

7100

14200

11.23

14

10

8.0

14.00

1.38

2.75

22.94

30.94

25.13

33.13

0.50

3/8-1/2

12000

24000

12.83

14

10

8.0

14.00

1.38

2.75

25.25

33.25

27.63

35.63

0.63

1/2-5/8

13000

26000

14.55

14

10

8.0

14.00

1.38

2.75

26.38

34.38

29.44

37.44

0.72
