ITEM NO(T) 型号

GCT0.5

GCT1

GCT1.5

GCT2

GCT3

GCT5

GCT10

Normal Capacity(T)额定载重量

0.5

1

1.5

2

3

5

10

Test load(T) 试验载荷

0.735

1.471

2.206

2.942

4.413

6.129

12.258

Which can gate through the

smallest curve radius (mm)

能通过的最小弯道半径

0.9

1

1

1.1

1.3

1.4

1.7

Suitable steel推荐用工字钢(mm)

68-94

68-100

88-118

94-124

106-110

142-180

142-180

Weight/KG 单重

4.8

7.7

12.8

12.8

24.5

43

88

ITEM NO(T) 型号

GCL0.5

GCL1

GCL1.5

GCL2

GCL3

GCL5

GCL10

Normal Capacity(T)额定载重量

0.5

1

1.5

2

3

5

10

Test load(T) 试验载荷

0.735

1.471

2.206

2.942

4.413

6.129

12.258

Which can gate through

The smallest curve radius (mm)

能通过的最小弯道半径

0.9

1

1

1.1

1.3

1.4

1.7

Suitable steel(mm) 推荐用工字钢

68-94

68-100

88-118

94-124

106-110

142-180

142-180

Weight/KG 单重

11.8

14.7

17.5

17.5

34.5

53

88

ITEM NO(T) 型号

GCA0.5

GCA1

GCA2

GCA3

GCA5

Normal Capacity(T)额定载重量

0.5

1

2

3

5

Test load(KN) 试验载荷

7.35

14.71

29.42

44.13

61.29

Which can gate through

The smallest curve radius (mm)

能通过的最小弯道半径

1.0

1.0

1.1

1.3

1.4

Dimensions(mm)主要尺寸

a

178

189

221

228

262

b

179

208

233

280

306

c

120

128

145

164

177

d

35

45

60

70

80

e

56

67

80

100

112

f

18

24

27

30

35

Suitable steel (mm) 推荐用工字钢

75-125

75-125

100-150

100-150

125-175

Weight/KG 单重

4.5

7.4

11.9

20

32.1

ITEM NO(T) 型号

GCF0.5

GCF1

GCF2

GCF3

GCF5

Normal Capacity(T)额定载重量

0.5

1

2

3

5

Test load(KN) 试验载荷

7.35

14.71

29.42

44.13

61.29

Which can gate through

The smallest curve radius (mm)

能通过的最小弯道半径

1.0

1.0

1.1

1.3

1.4

Dimensions(mm)主要尺寸

a

178

189

221

228

262

b

179

208

233

280

306

c

120

128

145

164

177

d

35

45

60

70

80

e

56

67

80

100

112

f

18

24

27

30

35

75

80

82

90

100

Suitable steel (mm) 推荐用工字钢

75-125

75-125

100-150

100-150

125-175

Weight/KG 单重

9.2

12.1

14.4

25

37.1
